Power Supply Module DC 3~5V to 5V 3A Boost Power Converter/Voltage Regulator DC 5V Adapter/Driver Module for MP3/MP4/PSP and DIY etc

  • Item ID #090394
Qty.:

List Price: $9.20 Our Price: $5.70Save 38%

Price(per unit)
1
$5.70		 2-4
$5.42		 5-9
$5.13		 10-29
$4.85		 30+
$4.56
Buy More: please contact us

It is a Power Supply Module/Adapter, Input voltage: DC 3~5V ( if Input voltage less than 3V, it can NOT reach rated output), Output Voltage: DC 5.0V, Output current: rated 3A , Suitable for MP3/MP4/PSP and DIY etc.


Other Products in DC Boost/Step Up

page 1 of 2 Previous Page Next Page
Introduction:
  • Size: 30 (L) * 18 (W) * 10 (H) mm
  • with voltage indicator
  • Ripple: 50mV MAX
  • efficient: up to 92%
  • With voltage indicator: input voltage less than 2.7V LED indicator off
Feature:
  • Module Properties: non-isolated step-up module (BOOST)
  • Input voltage: DC 3~5V ( if Input voltage less than 3V, it can NOT reach rated output)
  • Output Voltage: DC 5.0V
  • Output current: rated 3A (input voltage greater than 3V), short 5A (less than 10 seconds)
  • Conversion efficiency: 92% (the higher the input voltage, the higher the efficiency)
  • Switching frequency: 500KHz
  • Output ripple:
    • Input 4.2V Output 5V 3A 40mV (MAX)
    • Input 3.7V Output 5V 3A 50mV (MAX)
    • 20M-bandwidth
  • Operating Temperature: Industrial (-40°c to +85°c) (Ambient temperature 85°c less than 1A output current)
  • Full load temperature rise: 40°c
  • Quiescent Current: 200uA
  • Voltage regulation: ± 0.5%
  • Dynamic response speed: 5% 200uS
  • Short circuit protection: None (Please Install fuses and protection circuits at Input port.)
  • Input Reverse Polarity Protection: None (Please Series diode at the input port.)
  • Connection: Welding
Package Includes:
  • 1 x Mini DC Converter ( Power Supply Module/Voltage Regulator/Adapter )

Average
80%
5
0%
4
100%
3
0%
2
0%
1
0%
Power Supply Module DC 3~5V to 5V 3A Boost Power Converter/Voltage Regulator DC 5V Adapter/Driver Module for MP3/MP4/PSP and DIY etc
(2Reviews )4 of 5 Stars!

Write Review   |   Go to the Reviews Page

  • 4
    Lee Bledsoe
    11/14/2012

    Working well so far.

    I purchased this to boost a 1s lipo (3.7v) to 5v to power a rc receiver, servo system and gyro system. It has performed as described thus far (11/14/12) the unit is boosting my cells to 5.18 volts under load and no load.
  • 4
    PoliteX
    07/25/2012

    очень доволен

    качеством покупки остался очень доволен
